Overview
The 3.5 ton electric forklift is a powerful material handling solution for warehouses, factories, and logistics centers. With a rated capacity of 3500 kg, it provides robust lifting performance, smooth maneuverability, and zero emissions. Ideal for pallet handling, stacking, container loading, and medium-distance transport.
Equipped with an advanced battery system, ergonomic design, and reliable AC motor, the 3.5 ton electric forklift ensures long service life, reduced operating costs, and eco-friendly operation both indoors and outdoors on paved surfaces.
Features
✅ 3500kg load capacity for medium to heavy-duty operations.
✅ Compact turning radius suitable for narrow aisles.
✅ Battery options: lead-acid or lithium-ion with fast charging.
✅ AC drive motor with regenerative braking for energy efficiency.
✅ Ergonomic cabin with adjustable seat and excellent visibility.
✅ Reinforced chassis and mast for long-term durability.
✅ Safety features: overload protection, LED lights, horn, emergency stop.
✅ Customizable forks, lift heights, and optional attachments.
Product Parameters
| Rated lifting capacity(kg) | 3500 |
| Load center distance(mm) | 500 |
| With fork(mm) | 3850 |
| Without fork(mm) | 2700 |
| Full width(mm) | 1200 |
| No lifting of the mast height(mm) | 2100 |
| Height of the roof guard(mm) | 2100 |
| Maximum height during operation(m) | 3-6 |
| Distance from the seat surface to the ro(mm) | 1000 |
| Front | 1260 |
| Suspension travel(mm) | 350 |
| Rear suspension travel(mm) | 365 |
| Front wheel track(mm) | 1010 |
| Rear wheel track(mm) | 780 |
| Minimum ground clearance(mm) | 150 |
| Maximum lifting height(m) | 3-6 |
| Lift lever adjustment range(mm) | 1040 |
| Minimum turning radius (outer side)(mm) | 2315 |
| Minimum right-angle passage width(mm) | 3995 |
| Tire size (front)(mm) | 23*9-10 |
| Tire size (rear)(mm) | 18*7-8 |
| Lead-acid battery voltage/capacity(v/ah) | Lithium battery |
| Drive motor power(kw) | 7.5 |
| Oil pump motor power(kw) | 10 |
