Overview
The 3 ton electric forklift is a high-performance material handling solution for warehouses, factories, and logistics centers. With a rated capacity of 3000 kg, it combines strong lifting capability, smooth maneuverability, and zero emissions. Ideal for pallet handling, stacking, container loading, and transport over short to medium distances.
Equipped with an advanced battery system, ergonomic design, and reliable AC motor, the 3 ton electric forklift ensures long service life, reduced operating costs, and eco-friendly operation both indoors and outdoors on paved surfaces.
Features
✅ 3000kg load capacity for medium to heavy-duty operations.
✅ Compact turning radius for narrow aisles and warehouses.
✅ Battery options: lead-acid or lithium-ion with fast charging.
✅ AC drive motor with regenerative braking for energy efficiency.
✅ Ergonomic cabin design with adjustable seat and clear visibility.
✅ Reinforced chassis and mast for long-term durability.
✅ Safety features: overload protection, LED lights, horn, and emergency stop.
✅ Customizable forks, lift heights, and optional attachments.
Product Parameters
| Rated lifting capacity(kg) | 3000 |
| Load center distance(mm) | 500 |
| With fork(mm) | 3750 |
| Without fork(mm) | 2700 |
| Full width(mm) | 1200 |
| No lifting of the mast height(mm) | 2100 |
| Height of the roof guard(mm) | 2100 |
| Maximum height during operation(m) | 3-6 |
| Distance from the seat surface to the re(mm) | 1000 |
| Front(mm) | 1260 |
| Suspension travel(mm) | 350 |
| Rear suspension travel(mm) | 365 |
| Front wheel track(mm) | 1010 |
| Rear wheel track(mm) | 780 |
| Minimum ground clearance(mm) | 150 |
| Maximum lifting height(m) | 3-6 |
| Lift lever adjustment range(mm) | 1040 |
| Minimum turning radius (outer side)(mm) | 2315 |
| Minimum right-angle passage width(mm) | 3995 |
| Tire size (front)(mm) | 650-10 |
| Tire size (rear)(mm) | 500-8 |
| Lead-acid battery voltage/capacity(v/ah) | Lithium battery |
| Drive motor power(kw) | 5 |
| Oil pump motor power(kw) | 7.5 |
