Product Overview
This 4-ton electric forklift is an industrial-grade equipment specifically designed for heavy-duty material handling needs, offering exceptional performance and reliability. Featuring an advanced electric power system, it provides powerful performance while achieving zero emissions, making it an ideal choice for warehouses, logistics centers, and manufacturing plants.
Key Features
Powerful Loading Capacity: 4000kg rated load capacity, easily handles heavy material handling
Efficient Operation Performance: 230mm/s maximum lifting speed without load, 200mm/s lifting speed with full load
Excellent Maneuverability: 2550mm minimum turning radius, flexible operation in narrow spaces
Eco-Friendly & Energy Saving: Electric drive system, zero emissions, low noise, significantly reduced operating costs
Operating Comfort: Ergonomic designed cabin, adjustable seat and control lever
Product Parameters
| Fated lifting capacity(kg) | 4000 |
| Without fork(m) | 3000 |
| With fork(m) | 4070 |
| Wheel width(m) | 1250 |
| Frame width(m) | 1300 |
| Lifting door height(m) | 2250 |
| Guardrail height(m) | 2250 |
| Maximum working height(m) | 4200 |
| Axle spacing(m) | 1900 |
| Front suspension distance(m) | 350 |
| Front wheel distance(m) | 1100 |
| Rear wheel distance(m) | 1000 |
| Maximum lifting height without load(mm) | 3000 |
| Free lifting height(mm) | 100 |
| Lift angle (front/rear)(°) | 5/10 |
| Overall machine weight in standard unloaded state(kg) | 5800 |
| Maximum lifting speed without load(m/s) | 230 |
| Maximum lifting speed with full load(m/s) | 200 |
| Minimum turning radius(m) | 2550 |
| No-load maximum operating speed(km/h) | 14 |
| Loaded maximum operating speed(km/h) | 12 |
| Loaded maximum climbing gradient(%) | 12 |
| Center of load distance(m) | 500 |
| Minimum ground clearance of the mast(m) | 105/110 |
| Boost motor power(kw) | 18 |
