The WMS360 hydraulic wheel loader is a high-performance construction machine designed to handle diverse loading, lifting, and material transportation tasks with exceptional efficiency. Built with advanced hydraulic technology, this compact wheel loader delivers superior power, enhanced fuel efficiency, and easy operation, making it ideal for various construction, landscaping, agricultural, and municipal projects.
Core Competitive Advantages
Advanced Hydraulic System: Smooth and responsive controls for effortless operation and precise load handling.
Fuel-Efficient Engine: Low emissions and optimized fuel consumption reduce operating costs.
Robust Durability: Heavy-duty frame and components built for longevity in harsh environments.
Operator Comfort: Spacious cabin with ergonomic controls and excellent visibility for safer, less fatiguing operation.
Easy Operation & Maintenance
Designed with user-friendly controls and a centralized service panel, this wheel loader minimizes downtime and simplifies daily checks. The hydraulic quick-coupler allows fast attachment changes without manual intervention, boosting your operational efficiency.
| Performance Parameters | Dimensional Parameters |
|---|---|
| Engine Brand | KOPU/Runtong/Ballitong |
| Rated Power (HP) | 10/15/13.5 |
| Number of Cylinders | 1 |
| Air Intake Method | Natural |
| Emission Standard | Euro V/EPA |
| Rated Load Capacity (kg) | 200 |
| Maximum Load Capacity (kg) | 300 |
| Maximum Digging Force (kN) | 3.5 |
| Bucket Volume (m³) | 0.12 |
| Travel Speed (km/h) | 0-6 |
| Working Cycle Time (s) | 9 |
| Working System Pressure (bar) | 17-21 |
| Fuel Tank Capacity (L) | 5 |
| Operating Weight (kg) | 900 |
| Tire Model | 18×8.5-8 |
| Maximum Operating Height (mm) | 2450 |
| Height to Bucket Pin (mm) | 1870 |
| Overall Machine Height (mm) | 1300 |
| Maximum Height with Bucket Level (mm) | 1810 |
| Overall Length Without Bucket (mm) | 1550 |
| Overall Length With Standard Bucket (mm) | 2100 |
| Discharge Height (mm) | 1510 |
| Discharge Reach (mm) | 450 |
| Bucket Ground Tilt Angle | 27° |
| Bucket Maximum Height Tilt Angle | 114° |
| Wheelbase (mm) | 850 |
| Ground Clearance (mm) | 150 |
| Tail Length (mm) | 280 |
| Machine Width (mm) | 1050 |
| Bucket Width (mm) | 1000 |
